Engine Specifications

SPECIFICATIONS

Type4 cylinders
Air intake typeTurbocharged
Cooling modeWater cooling
Governor modeMechanical
Bore x Stroke(mm)108 x 130 mm
Compression ratio19:1
Rated speed(rpm)1500
Displacement(L)4.8
Starter Motor12V

OUTPUT & CONSUMPTION

Rated power(without fan)(kW)92.8
Standby power(without fan)(kW)97.8
Fuel consumption(g/kWh)24.2
Oil consumption(L/h)0.3% of fuel consumption (by weight)
Oil capacity including filter(L)13.0
Emission compliantEU Stage II / EPA Tier 2 (comparable)

DIMENSIONS

LIQUIDS & HEAT

27°C air consumption(m³/min)90.0
Exhaust gas flow(m³/min)16.75
TEST
