Engine Specifications

SPECIFICATIONS

Type4 cylinders
Air intake typeTurbocharged
Cooling modeWater cooling
Governor modeElectronic
Bore x Stroke(mm)108 x 130 mm
Rated speed(rpm)1500
Displacement(L)4.76
Starter Motor12V

OUTPUT & CONSUMPTION

Rated power(without fan)(kW)117.6
Standby power(without fan)(kW)124.0
Fuel consumption(g/kWh)29.3
Oil consumption(L/h)0.3% of fuel consumption (by weight)
Oil capacity including filter(L)17.0
Emission compliantEU Stage II / EPA Tier 2 (comparable)

DIMENSIONS

LIQUIDS & HEAT

27°C air consumption(m³/min)150.0
Exhaust gas flow(m³/min)23.15
