Engine Specifications

SPECIFICATIONS

Type12 cylinders, At Vee
Air intake typeTurbocharged and Aftercooled
Cooling modeWater cooling
Governor modeECU
Bore x Stroke(mm)150 x 185
Compression ratio15:1
Rated speed(rpm)1500
Displacement(L)39.2

OUTPUT & CONSUMPTION

Rated power(without fan)(kW)1318
Standby power(without fan)(kW)1450
Fuel consumption(g/kWh)353.7
Oil consumption(L/h)≤ 0.3%
Oil capacity including filter(L)155
Emission compliantN/A
The flywheel shell interfaceSAE 0
The flywheel shell interface18" flywheel

DIMENSIONS

LIQUIDS & HEAT

TEST
