Engine Specifications

SPECIFICATIONS

Type16 cylinders, At Vee
Air intake typeTurbocharged and Aftercooled
Cooling modeWater cooling
Bore x Stroke(mm)150 x 185
Compression ratio15:1
Rated speed(rpm)1500
Displacement(L)52.3

OUTPUT & CONSUMPTION

Rated power(without fan)(kW)1680
Standby power(without fan)(kW)1800
Fuel consumption(g/kWh)446.8
Oil consumption(L/h)≤ 0.3%
Steady state speed regulation(%)<0.5
Oil capacity including filter(L)171
Emission compliantN/A
The flywheel shell interfaceSAE 0
The flywheel shell interface18" flywheel

DIMENSIONS

LIQUIDS & HEAT

TEST
