Engine Specifications

SPECIFICATIONS

Type6 Cylinder
Air intake typeTurbocharged
Cooling modeWater cooling
Governor modeElectronic
Bore x Stroke(mm)108 x 130 mm
Compression ratio17:1
Rated speed(rpm)1500
Displacement(L)7.15

OUTPUT & CONSUMPTION

Rated power(without fan)(kW)215.4
Standby power(without fan)(kW)240.4
Fuel consumption(g/kWh)54.5
Oil capacity including filter(L)29
Emission compliantEU Stage 2 (Non-Road Directive 97/68/EC)
The flywheel shell interfaceSAE 2
The flywheel shell interfaceFlywheel for flexplate, 10 in and 11.5 in disc

DIMENSIONS

LIQUIDS & HEAT

TEST
