Engine Specifications

SPECIFICATIONS

Type6 cylinders, Vertical Inline
Air intake typeTurbo Charged, Intercooled
Cooling modeWater cooling
Governor modeElectronic
Bore x Stroke(mm)127 x 165
Compression ratio16:1
Rated speed(rpm)1500
Displacement(L)12.54

OUTPUT & CONSUMPTION

Rated power(without fan)(kW)368
Standby power(without fan)(kW)405
Fuel consumption(g/kWh)85
Oil consumption(L/h)≤ 0.2%
Oil capacity including filter(L)30
Emission compliantN/A
The flywheel shell interfaceSAE 1
The flywheel shell interface14" flywheel

DIMENSIONS

LIQUIDS & HEAT

TEST
