Engine Specifications

SPECIFICATIONS

Type6 Cylinder
Air intake typeTurbocharged
Cooling modeWater cooling
Governor modeElectronic
Bore x Stroke(mm)144 x 165 mm
Compression ratio16.5:1
Rated speed(rpm)1500
Displacement(L)16.12

OUTPUT & CONSUMPTION

Rated power(without fan)(kW)430
Standby power(without fan)(kW)473
Fuel consumption(g/kWh)101.0
Oil consumption(L/h)0.10
Oil capacity including filter(L)42
Emission compliantEU Stage 2 (Non-Road Directive 97/68/EEC)
The flywheel shell interfaceSAE 1
The flywheel shell interfaceFlywheel for 14 in flex. plate and flexible coupling

DIMENSIONS

LIQUIDS & HEAT

TEST
