Engine Specifications

SPECIFICATIONS

Type6 cylinders, Vertical Inline
Air intake typeTurbocharged and Aftercooled
Cooling modeWater cooling
Governor modeECU
Bore x Stroke(mm)127 x 165
Compression ratio15.2 : 1
Rated speed(rpm)1500
Displacement(L)12.54

OUTPUT & CONSUMPTION

Rated power(without fan)(kW)450
Standby power(without fan)(kW)490
Fuel consumption(g/kWh)123.1
Oil consumption(L/h)≤ 0.2%
Steady state speed regulation(%)<0.5
Oil capacity including filter(L)34
Emission compliantN/A
The flywheel shell interfaceSAE 1
The flywheel shell interface14" flywheel

DIMENSIONS

LIQUIDS & HEAT

TEST
