Engine Specifications

SPECIFICATIONS

Type6 cylinders, Vertical Inline
Air intake typeTurbocharged and Aftercooled
Cooling modeWater cooling
Governor modeElectronic
Bore x Stroke(mm)150 x 185
Compression ratio15:1
Rated speed(rpm)1500
Displacement(L)19.6

OUTPUT & CONSUMPTION

Rated power(without fan)(kW)610
Standby power(without fan)(kW)670
Fuel consumption(g/kWh)171
Oil consumption(L/h)≤ 0.3%
Oil capacity including filter(L)61
Emission compliantN/A
The flywheel shell interfaceSAE 1
The flywheel shell interface14" flywheel

DIMENSIONS

LIQUIDS & HEAT

TEST
