FEATURES
- Maximum 8.0kVA, 230v, 3000RPM
- 28 litre built in tank
- Open Frame with wheels and handle
- Electric and Recoil Pull Start
- Single Phase Output
- Ideal for work-sites and builders
- Compact robust design, Solid Wheels
- 2 x 230v Sockets Output
- 12v Battery Charging output
- Circuit Breaker (2P)
PERFORMANCE
Prime power (PRP) | 7.5 kVA |
Standby power (LTP) | 8.0 kVA |
Power factor | 1 φ |
Frequency | 50 Hz |
Voltage | 230 V |
GENERAL ENGINE DATA
Engine brand | Bundu Power |
Engine model | GK460 |
RPM | 3000 |
Engine Type | Single cylinder, air-cooled, 4-stroke, OHV |
Starting System | Electric & Recoil |
Displacement | 0.458 l |
Compression Ratio | 8.8:1 |
Engine Power | 8.2kW (kW / RPM) |
Fuel Type | Petrol |
Recommended Oil | 10W-30 |
Low Pressure Alert | NA |
Low Fuel Cut Out | NA |
Description | Petrol Generator |
PLEASE NOTE
This generator is not suitable for use as a backup to a solar inverter due to harmonic feedback. Read more here.GENERAL DATA
Generator Controller | 3-in-1 Display Meter |
Structure Type | Open Frame |
Noise Level (dBA @ 7m) | NA |
AVR | Constant voltage AVR |
Weatherproof | No |
Indoor Use | No |
Excitation Mode | Self Excitation |
ISO9001 Certified | Yes |
CE Certified | Yes |
ALTERNATOR DATA
Alternator Model | TFDY-6.0 |
Rated Current (A) | 34.7 Amps Per Phase |
Pole Number | 2 |
Phase Number | Single Phase |
GENERATOR DIMENSIONS
Length | 720 mm |
Width | 530 mm |
Height | 610 mm |
Weight | 87 kgs |
Tank Capacity | 28 l |
BATTERY DATA
Brand | Dynavolt or Equiv |
Model | MG9-BS |
Voltage | 12V |
Quantity | 1 |
Capacity | 12Ah |
Dimensions | L150*W86*H105 mm |
Type | Maintenance Free |
FAQ
Does the price include installation?
No, the price doesn't include installation. Installations are all different and require varying length of cable, time and distances to be travelled. In addition to this installations need to be done by a qualified electrician to issue a valid Certificate of Compliance (COC) for your insurance. We will gladly recommend a qualified local installer, please ask your Sales Consultant for more information.
Do we offer installation?
No, but we do have recommended installers throughout Southern Africa who will be able to assist you with your installation and sizing your generator.
Does the price include delivery?
All prices exclude delivery. Due to the nature of the goods and their size they have to be delivered by a specialised truck and rigging crew. Hence delivery is charged extra based on the distance and complexity of the delivery.
Do I need anything else to connect the generator?
Yes, you'll need either an Automatic (ATS) or Manual change over switch in order to link the generator into your properties electrical distribution board.
Tell me about the Warranty?
The warranty is 12 Months or 500 Hours whichever occurs first. It is a limited warranty. Travel to site is not included in the warranty. The goods need to be returned to us or a call out will be charged. Please refer to the Terms and Conditions of sale and the Warranty Card for further information on the warranty. Warranty is held with the agency where you bought the generator. If you have purchased your generator in Johannesburg then the warranty is held in Johannesburg etc.
Price Validity
Pricing is valid whilst stock lasts and is subject to change without prior notice. Pricing on the website is indicative and should always be confirmed by Bundu Power in the form of a written quotation.
Can I make the generator quieter?
Silent generators are designed to minimise sound and optimise airflow through the generator canopy. Any restriction of the airflow in any way will lead to the generator over-heating and it will cause damage to the generator.
We do not recommend using any after-market silencing solutions, this will likely void your warranty and could be a fire hazard.
Generators should be installed outside with at least one meter clear around it to allow for optimal working conditions. DO NOT install inside a room without appropriate ventilation.
Petrol Generators should always be drained and the fuel system cleaned when not in use or put into storage.
