BATTERY Battery Module Type HV51289F Cell Capacity 280Ah Battery Voltage Range 672~864V Nominal Current 140A (0.5C) System Storage Power 215kWh AC (on-grid) Nominal Power 100kW AC Nominal Voltage 400V Wiring 3P4L+PE Nominal Frequency 50Hz AC Maximum Current 158A Max.number of BESS in parallel 12 AC (off-grid) Nominal Power 100kW AC Nominal Voltage 400V Wiring 3P4L+PE Nominal Frequency 50Hz AC Maximum Current 158A Unbalanced Load Capacity 100% On-grid Switching to Off-grid Time < 20ms Off-grid Switching to On-grid Time < 20ms Max.number of BESS in parallel 5 PHOTOVOLTAIC INPUT MPPT Voltage Range 200-670V MPPT channels Up to three Input Power Single channel 50kW SYSTEM Dimensions(W*D*H) 1850*1200*2250mm Weight ≈3300kg Air Conditioner Power 3kW (Cooling capacity) Operation Temperature -20~50°C Operation Humidity 0 ~ 95% (Non-condensing) Protection Level IP55 Anti-corrosion Level C3 Noise Level < 76dB Altitude < 3000m Cooling System Fan Cooling Display Touch screen (optional) Firefighting Aerosol/Heptafluoropropane (FM-200)/Perfluoro EMS Communication Ethernet Certification CE/CQC Specifications & Quote Download Get a Quote Key Benefits All-In-One Integrated Cabinet All safety measures are built into the cabinet. Can be installed inside or outside. Parallel multiple units. Single cabinet: 100kW Inverter, 215kWh Storage Lithium storage are replaceable
