FEATURES
- Maximum 22.0 kVA, 400 V, 1500 RPM
- 55 litre tank for 13 hrs @ 75% Load
- Industrial brushless alternator with AVR
- Steel baseframe, retention basin & fuel tank with sensor
- World wide after sales service and technical support
- Test report, manuals and electrical drawings supplied
- Modular design, open and silent version available
- Warranty
PERFORMANCE
| Prime power (PRP) | 20.0 kVA |
| Prime power (PRP) | 16.0 kW |
| Standby power (LTP) | 22.0 kVA |
| Standby power (LTP) | 17.6 kW |
| Power factor | 0.8 |
| Frequency (Hz) | 50 Hz |
| Voltage (V) | 400 V |
GENERAL ENGINE DATA
| Genset Controller | |
| Engine brand | CK |
| Engine model | 404A-22G1 |
| Cylinders | 4 |
| Speed | 1500 RPM |
| Cubic capacity | 2.22 |
| Air intake | Aspirated |
| Standard voltage | 12 V |
| SAE | 4-7½ |
| BMEP | 669 |
| Cooling | Water |
| Flywheel P.R.P. | 18.7 kW |
| Flywheel Stand-by | 20.6 kW |
EMISSIONS
| TA Luft | Not available |
| TA Luft2 | Not available |
| EPA | Not available |
| Stage | Not available |
GENERATOR DIMENSIONS
| Length | 1660 mm |
| Width | 770 mm |
| Height | 1330 mm |
| Weight | 690 kgs |
| Tank Capacity | 55 l |
FUEL CONSUMPTION
| Fuel Cons. at 110% | 6.1 l/h |
| Fuel Cons. at 100% | 5.3 l/h |
| Fuel Cons. at 75% | 4.0 l/h |
| Fuel Cons. at 50% | 2.9 l/h |
| Fuel Cons. at 25% | 0.0 l/h |
SPEED REGULATION
| Electronic regulator | Not available |
| Precision class |
ENGINE LIQUIDS
| Oil quantity | 10.6 l |
| Antifreeze quantity | 3.6 l |
HEAT FROM ENGINE
| Heat from radiator | 17.0 kW |
| Heat from exhaust | 14.0 kW |
| Heat from radiation | 3.3 kW |
ALTERNATOR
| Brand | STAMFORD |
| Model | PI144D |
| Continuous Power | 20.0 kVA |
| Standby Power | 22.0 kVA |
| Connection | Series star |
| Phases | Three phases with neutral |
| Winding | 12 terminals Winding 311 |
| Terminal No | 12 |
| IP Protection | 23 |
| Regulator | AS480 |
| Precision | 1.0 ± % |
HEAT FROM EXHAUST
| Exhaust temperature | 445 °C |
| Cooling air flow | 29.40 m³/min |
| Combustion air flow | 1.45 m³/min |
| Exhaust gas flow | 3.64 m³/min |
PLEASE NOTE: ALL ratings are approximate and at SEA LEVEL. Engines need to be de-rated for altitude. A rough guide to de-rate performance is 1% for every 100m above sea level. I.e: A 20kVA at sea level is an 18kVA at 1000m above sea level (10% less) etc.
